- Operation language
- Language :
- English, German, Italian, Spanish, French, Portuguese, Russian, Turkish, Polish, Chinese
- Mechanical data
- Protection :
- IP66 / NEMA 4X
- Dimensions :
- 144 mm (5.67 in) x 144 mm (5.67 in) x 99 mm (3.89 in)
- Weight :
- Aluminium enclosure | 1.04 kg (2.3 lb)
- Polycarbonate enclosure | 0.7 kg (1.5 lb)
- Terminal connections :
- AWG 26 to 14 (0.14 to 2.5 mm2)
- pH/ORP, 2-electrode conductivity, 4-electrode conductivity, toroidal conductivity, pION (custom user programmable),
EZLink Digital (pH/ORP)
- Input
- pH/ORP/pION sensor types
- pH : Glass, Antimony (Sb)
- ORP : (Redox): Platinum (Pt), Gold (Au)
- pION : Custom user-programmable
- –20 to 60 °C (–4 to 140 °F)
- Electrical
- Power supply (FF models and PA models)
- Supply voltage :
- 9 to 32 V DC (General purpose installations)
- 9 to 24V DC (Intrinsically safe Ex ia installations)
- Power supply (HART models)
- Supply voltage :
- 14 to 42 V DC (General purpose installations)
- 14 to 30 V DC (Intrinsically safe Ex ia installations)
- Polarity safe
- Lift off voltage: 12 V DC
- Connectivity / Communications (options)
- FOUNDATION™ Fieldbus™
- PROFIBUS™ PA
- HART™
- Polycarbonate enclosure :
- ATEX/IECEx
- II 1G Ex ia IIC T4 Ga
- – 20 ⁰C </ Ta </ + 60 ⁰C, IP66
- cFMus (IS)
- Class I Div I, Gps ABCD T4
- Class II Div I, Gps EFD T4
- – 25 ⁰C </ Ta </ + 60 ⁰C, IP66
- Exia
- Aluminium enclosure :
- ATEX/IECEx
- II 1G Ex ia IIC T4 Ga
- – 20 ⁰C </ Ta </ + 60 ⁰C, IP66
- cFMus (IS)
- Class I Div I, Gps ABCD T4
- Class II Div I, Gps EFD T4
- – 25 ⁰C </ Ta </ + 60 ⁰C, IP66
- Exia
- cFMus (NI)
- Class I, Div 2, Gps ABCD
- Class II, Div 2, Gps FG
- Class III
- – 25 ⁰C </ Ta </ + 60 ⁰C, IP66
